Community · 30 figures

Machines other people drew with the skill, each with the prompt that made it.

  • 10 authors
  • 4 models
  • rebuilt from source
  • updated 12 Oct 2026

Every figure here was sent to wheresryan22/anatomy-community as source, built again from it in a locked sandbox, and photographed there at one size with its frame, captions and readouts taken away, so only the object is left.

Figures

30 figures

Cu/diamond composite: post-mixing vs pre-coating@entityExplain how copper/diamond composites are made, comparing the post-mixing route (a carbide-forming interfacial layer on the Cu particles, mixed with uncoated d…Claude Opus 5.5SVGFilm projector@entitylets do the film projectorClaude Opus 5.5≈ 16 min360kGame Boy@entityA 1989 Game Boy you can play: the D-pad and A/B buttons move and jump a sprite on the 160x144 four-green screen.Claude Opus 5.5SVGGumball machine@entityA coin-op gumball machine: put in a quarter and turn the crank, the coin wheel lets exactly one gumball fall, and it rolls down the chute against the flap at t…Claude Opus 5.5SVGJukebox@entityA 1950s jukebox: pick a record and the carousel turns, the arm lifts it onto the turntable and the tonearm plays it at 45 rpm.Claude Opus 5.5SVGLever espresso machine@entityA spring-lever espresso machine: pull the lever to pre-infuse at boiler pressure, release it and the spring drives the piston to about 9 bar and lets it fall a…Claude Opus 5.5SVGNES controller@entityAn NES controller with the shell cut away: press a button, its rubber dome closes the carbon contact, and each poll the 4021 shift register sends all eight but…Claude Opus 5.5SVGPolaroid camera@entityA Polaroid instant camera: press the shutter, the flash fires, the rollers push the print out through the reagent, and the picture develops from blue-grey to f…Claude Opus 5.5SVGPop-up toaster@entityA two-slot pop-up toaster with the side cut away: press the lever, the nichrome glows, the bread browns with the heat it takes in and the toast pops up.Claude Opus 5.5SVGWalkman cassette player@entityA 1979 Walkman-style cassette player: press play and watch the tape run past the head, with both reels turning at their true speeds.Claude Opus 5.5SVGFloating-caliper disc brake@gudguliai/anatomy build the brake mechanism from a 2013 Kia Sorento — how a floating caliper clamps a vented rotor, interactiveMuse Wonder3DHow Machu Picchu was built@jcroccomendez/anatomy explain how Machu Picchu was built, interactive: an Inca terrace cutaway with stone fitting, drainage, earthquakes and hauling a block up a rampClaude Opus 5.5SVGPowerbank anatomy: how a 25,000 mAh 200 W powerbank works@minhaajreuse that repo to create an explain on how powerbanks work and its anatomy use a simple react page to demonstrate that. use previous examples of back propagatio…Muse Spark 1.3SVGClick pen@nader0913/anatomy explain how a click pen's mechanism worksClaude Opus 5.5SVGFlush toilet@nader0913/anatomy explain how a flush toilet worksClaude Opus 5.5SVGFour-stroke engine@nader0913/anatomy explain how a four-stroke car engine worksClaude Opus 5.5SVGGeneva drive film advance@nader0913/anatomy explain how a Geneva drive turns continuous rotation into intermittent motion, as a film projector's frame advanceClaude Opus 5.5SVGSwiss lever escapement@nader0913/anatomy explain how a mechanical watch's lever escapement keeps timeClaude Opus 5.5SVGOpen differential@nader0913/anatomy explain how a car's open differential lets the wheels turn at different speedsClaude Opus 5.5SVGCombination padlock@nader0913/anatomy explain how a combination padlock opensClaude Opus 5.5SVGPin tumbler lock@nader0913/anatomy explain how a key opens a pin tumbler lockClaude Opus 5.5SVGWankel rotary engine@nader0913/anatomy explain how a Wankel rotary engine worksClaude Opus 5.5SVGZipper@nader0913/anatomy explain how a zipper worksClaude Opus 5.5SVGAutomatic watch@srirangam-r/anatomy explain how an automatic self winding mechanical watch works, interactiveClaude Opus 5.5≈ 1 h 25 min718kKeyboard switch, sawn open@taqh/anatomy explain how mechanical keyboard switches workClaude Opus 5.5≈ 46 minBMW iX3 on the bench@tiago-varandasvisualize a car, a new bmwClaude Opus 5.5≈ 3 h 5 min362kSteering Column Impact Test@vinayanand3Install the Anatomy skill and use it to improve my steering column. Then: fix the drawing to follow the industry standards by rebuilding it as the regulatory t…Claude Opus 5.5SVGDial indicator@wheresryan22/anatomy explain how a dial indicator measures runout, interactiveModel not givenSVGRaptor engine on the test stand@wheresryan22/anatomy explain how a full-flow staged combustion rocket engine works, as a Raptor on a test stand, interactiveModel not givenWebGLRipple tank@wheresryan22/anatomy explain how waves interfere, as a school ripple tank, interactiveModel not givenWebGL

Add yours

Make a figure with Anatomy as usual. Then, in the same session, ask your agent:

publish this figure to the Anatomy community gallery

It asks for a title, a short id and your GitHub name, shows what it will send, and opens the pull request for you. Without a terminal, put the source in a Gist and fill in the Submit a figure form.

Say which model drew it, with --model or the form's Model field, and its maker's mark shows on the card. The rules, and what the checks do with your code, are in the repository's README.
