M 290 Metal 3D Printer, Simulated
@EntangledQuantum· 13 Oct 2026
- Model
- Claude Opus 5.5
- Agent
- Claude Code
- Kind
- SVG
- Tags
- lpbf, metal-3d-printing, simulation, manufacturing
- Licence
- MIT
- Added
- 13 Oct 2026
- Source
- entangledquantum/m290-metal-3d-printer
Prompt
Built for learning how an EOS M 290 laser powder bed fusion metal 3D printer works: a cut-away of the machine building a twisted turbine blade, with the scanner head open so the galvo mirrors can be seen steering the beam, where laser power, scan speed and hatch distance set the melt pool, the scan tracks and the porosity of the part.
Source
The build.mjs that drew it, and its figure.json, are on GitHub. Something wrong with it? Report this figure.
